Main Feature:1 Working table equipped with driving motor to ensure smooth material feeding
2 Brand new designed control panel with digital display
3 Short material roller,ensure short materials can be conveying smoothly
4 Universal joint feeding,precise,durable and requires minimum maintenance
Machine Data:| Model | MB4023 |
| Processing Width | 20-230mm |
| Processing Thickness | 5-125mm |
| Feeding Speed | 5-20m/min |
| Feeding Power | 2.2KW |
| Knife Speed | 6000r/min |
| Lower Horizontal Shaft Power | 4-5.5KW |
| Upper Horizontal Shaft Power | 7.5KW |
| Right Side Vertical Knife Arbor Power | 4KW |
| Cross Beam Lifting and Lowering Power | 0.75KW |
| Total Power | 23.95KW |
| Total Weight | 2700KG |
Advantage:
1.Stepless feeding,feeding speed 5-24M/min
2.Each main spindle is drove by independent motor with powerful cutting
3.Main spindle adjustment concentrated in front of the set, easy to operate
4.Hard chromium plated worktable surface,durable
5.Equipped with short material auxiliary device, effectively improve the smooth feeding of short material
6.Multiple lower roller,improve feeding efficiency
7.Famous brand electric components are applied for good stability
8.All spare parts are thick and solid designed for high precision,high stability and high reliability
9.Equipped with Pneumatic compressed feeding roller,and pressure can be adjusted in different stages,favorable for smooth feeding timbers with different thickness
10.Fully sealed safety shield ,can avoid dust flying and isolating noises,meantime prevent unnecessary work injuries
